Rhino Tanks | Aquadam

The Future of Water Storage

The strongest, most durable steel tank ever built in South Africa.

The Rhino Tank represents a major evolution in steel water storage technology.

Engineered with Fusion Bonded Epoxy (FBE) coating inside and out, Rhino Tanks deliver maximum corrosion resistance, zero liner degradation, and exceptional longevity — even in the harshest African environments.

No plastic liners. No maintenance headaches.

Just solid, industrial-grade protection — built to outlast and outperform

Learn more About Our Rhino Tanks

WHY CHOOSE RHINO TANK

1. Fusion Bonded Epoxy Coating – Inside & Out

Each steel panel is grit-blasted, pre-heated, and coated with electrostatically applied epoxy powder that fuses permanently to the steel surface at over 200°C, forming an impermeable, chemical-resistant layer.

This advanced coating prevents rust, pitting, and UV degradation, ensuring a lifespan of over 40 years with minimal maintenance.

2. Engineered Strength

Manufactured from high-tensile structural steel panels, Rhino Tanks are precision-bolted and sealed with high-performance compounds to ensure absolute watertight integrity — from 20,000 L up to 5 million L and beyond.

3. No Plastic Liner Required

Unlike traditional Zincalume or lined tanks, Rhino Tanks have no liners to puncture, shrink, or degrade. The FBE coating system eliminates micro-leak risks and simplifies installation.

4. Modular & Scalable Design

Delivered in compact panel form for easy transport and assembly anywhere in Africa. Panels are fully interchangeable and repairable on-site — ideal for mines, municipalities, and agricultural developments.

5. Aesthetic, Clean, and Environmentally Sound

Available in matte black, charcoal, or industrial grey, the Rhino Tank complements modern architecture while being 100% recyclable.

No plastic, no leachates — only clean water storage.

Exceptional Quality Design Codes & Standards Modular Design

TECHNICAL SPECIFICATIONS

Feature
Tank Sizes

Material

Coating Type

Coating Thickness

Adhesion Class

Corrosion Resistance

Temperature Range

Sealing Compound sealant

Foundation Options concrete slab

Compliance

Specification
20,000 L – 5,000,000 L
High-tensile carbon steel

Fusion Bonded Epoxy (FBE), inside and outside

250–400 µm (typical)

Class 1 – ASTM D4541

3,000 hrs salt-spray test (ASTM B117)

T-30°C to +85°C

Industrial-grade mastic and epoxy joint sealant

Concrete ring beam or reinforced concrete slab

AS/NZS 4020, ISO 12944-9, SANS 10160

APPLICATIONS

Potable water storage

Municipal & domestic

Agriculture & irrigation

Long-life field reservoirs

Rainwater harvesting

Ideal for sustainable projects

Fire suppression systems

Compliant with SANS & FM standards

Mining & industrial process water

Chemical and corrosion resistant

Wastewater & effluent holding

Non-permeable interior coatin

HOW IT’S BUILT

Every Rhino Tank begins as pre-blasted, pre-heated steel plates.

These panels undergo a multi-stage cleaning and preparation process before the Fusion Bonded Epoxy powder is applied and cured.

The result: a single, uniform coating chemically fused to the steel — not just painted on.

Final assembly is quick and modular. Panels are bolted together on-site, sealed with an industrial-grade epoxy joint system, and ready to fill within days.
